DEPSTECH USB / Wireless Car Endoscope

Product Features and Description

• Model : 86T-5.0MP Type-C endoscope
• Compatible device :Android 5.0+ / Windows PC/MAC
• Endoscope Diameter : 8.5mm / 0.33 in
• Horizontal viewing Angle : 80°
• Focal Distance : 7-40cm / 2.75-15.74in(Updated CamTele 2.0 Tech)
• USB Type : Type -C
• Waterproof : IP67
• Maximum resolution : 2592*1944 (Updated Bluart 2.0 Tech. It is clearer than 1080P )
• Working Voltage : DC 5V/2A

APP Download:

• Android 5.0+ : ” DEPSTECH-VIEW “
• Windows PC : “DEPSTECH-VIEW” or “camera”
• MAC: “PhotoBooth”
• Note: NOT support iPhone, iPad.

Desription of 86T-5MP Borescope for Smartphone Android iOS Windows

【Ultra HD 5MP (2592*1944) Camera】

The borescope camera with 0.33in ultra thin probe can inspect any hard-to-reach places without efforts. 5.0MP camera helps shoot 2592*1944P super clear photos and smooth videos.(Note: The 1944P 5.0MP pixcel is better than 1080P 2.0MP). Most of Endoscope is 1080P 2.0MP, 1944P 5.0MP is better than 1080P 2.0MP.

【Waterproof Probe & Semi-Rigid Cable】

These 6 brightness adjustable LED ensures enough light on in the dark place and the light control button adjusts the brightness as you need; Work even underwater place(no deeper than 3.3ft) such as sewer and pipeline inspection.

【USB Connection, Easy Set-up】

This endoscope camera can connect with Android smart phone, windows computer and MacBook via the micro USB, USB and type-c adapter easily and quickly. Download the driver and see real-time images on screen.

Work in Multi Devices

1. Compatible with PC with Windows XP / 7 / 8 / 10 and MacBook OS.
2. Compatible with smart Phone with Android 5.0+ system, also your phone needs to support OTG and UVC function.

Down the App: Please go to Google Play Store to download “DEPSTECH-View” App on your device.（NOTE: Please visit our official website to install the latest version of the APP for Android 10.0+ user）

【6 Brightness Adjustable LED】

Even in a dim area or too much exposure outside environment, this HD inspection camera can capture optimum images with the help of its brightness adjustable LED lights. The brightness can be adjusted according to your inspecting needs.

【CamTele 2.0 Tech】

DEPSTECH new CamTele 2.0, we expand the focus range up to 15.7 in. You can observe things in detail easily and quick to solve the problems, saving your treasure time and money.

【Packing List of 1944P 5MP Endoscope】

1 x 86T USB Endoscope (5MP 8.5mm )
1 x USB cable
1 x Set Accessories – Mirror, Hook, Magnet
1 x User Manual
1 x Original Box

Desription of WF280-5MP

Specification for WF028-5MP:

• Resolution: 2592×1944
• Camera Diameter: 8.5mm
• WIFI Transmission Distance:10 meter
• Battery Capacity: 2200 mAh
• Focal Distance: 7CM-40CM
• Power Supply: DC 5V
• support system：Android / IOS / Windows
• Cable length: 5 meters
• LED: 6 LED lights

Semi-rigid Cable, Multiplying the Applications

Internal iron wire supports the flexibility of the line.
Proper hardness and softness are the key to the versatility of the product, a perfect tool for HVAC inspection, vent pipe, machine equipment, engine, automotive, and boat maintenance.

Delicate Accessories, Fixing More Glitches

The mirror, magnetic and hook, made of the premium materials from the same place as the endoscope.
It will be a utility and helpful tool to shoot the trouble you detect in the gloomy environment.

Package List:

1 x WF028-5MP Wifi Endoscope
1 x Charging Cable
1 x Set Accessories – Hook,Mirror,Magnet
1 x User Manual
1 x Original Box

Desription of WF280-2MP Dual Lens

• Cable Length : 5m / 16.4 FT
• Camera Diameter : 7.9mm / 0.31 inch
• Sensor : 2*2MP CMOS
• Resolution: 1920*1080 (highest) MJPG
• View Angle : 2*72°
• Focal Distance：front camera 3-8cm /1.2-3.9in ; side camera 2-6cm / 0.8-2.4in
• Power Source : 2200mAh
• Power input : DC 5V/2A
• Support : Android 5.0+ / IOS 9.0+ phone

1080P Dual Lens:

The dual-lens endoscope can inspect the range of 70° in front and its side with the ergonomics design. Allow you to explore narrow areas without obstacles.The front camera focal range is 3-8cm / 1.2-3.1in and the side camera is 2-6cm / 0.8-2.4in. Easy to operate, the wireless HD inspection camera is ready to use after fully charged

Three Display Screens:

The video endoscope camera provides three display screens. One is the Front image, one is the side image and the last is both front and side image, One button on the app to switch the front camera and side camera. Take images from different lenses of the endoscope as needed. Fully meet your daily needs

Package List:

1 x WF028 Dual Lens 2MP Wifi Endoscope.
1 x Charging Cable.
1 x Set Accessories – Hook,Magnet.
1 x User Manual.
1 x Original Box.
